Semi-automatic Cathode Stripping Machine

The semi-automatic cathode stripping machine is an integrated unit designed for cathode plate handling, manual stripping, and copper sheet stacking in electrowinning plants. Compared with fully automatic systems, it provides a compact structure, lower investment, and simple operation, making it ideal for medium-capacity operations.

Functions of Main Modules

1. Main Conveying System: Receiving Conveyor Line

Semi-automatic Cathode Stripping Machine

Function: As the core path for material circulation, it is responsible for conveying cathode plates from the receiving area to the manual stripping area.

2. Core Processing Area: Manual Stripping Area

Semi-automatic Cathode Stripping Machine

Function: Workers manually strip off the metal layer from the cathode plate here.

3. Output System: Arrangement Output Line

Semi-automatic Cathode Stripping Machine

Function: The stripped cathode plates are output through the arrangement output line.

4. Auxiliary Structure: Sliding Track

Semi-automatic Cathode Stripping Machine

Function: The stripped copper sheets slide from the conveyor to the stacking platform via this track.

5. Terminal Point: Stacking Device

Semi-automatic Cathode Stripping Machine

Function: Used for stacking the stripped copper sheets.

6. Sampling Station

Semi-automatic Cathode Stripping Machine

Overall Dimensions (Length * Width * Height): Approximately 2550 * 490 * 3060 mm

Function: Conduct random sampling on the stripped copper plates. Samples are punched out to test indicators such as copper purity, thickness and component uniformity, so as to ensure the product quality meets the standards.

Key Features

  • Compact & Modular – easy installation and smooth integration with existing EW plants.

  • Low Investment – significantly lower cost compared to fully automatic machines.

  • Easy to Operate – retains manual stripping for core process, with semi-automation in material flow.

  • Quality Assurance – equipped with sampling station for consistent copper quality checks.

  • Flexible Capacity – suitable for medium-scale production plants.

  • Low Maintenance – fewer moving parts, easy upkeep.

FAQ

Q1: What capacity is this machine suitable for?
A1: Designed for small to medium production, typically below 100–200 plates/hour.

Q2: What is the main advantage compared with a fully automatic stripping machine?
A2: Lower investment cost, simpler structure, easier maintenance.

Q3: Can the system be customized?
A3: Yes, conveyor length, stacking capacity, and sampling station can be designed based on project needs.

Q4: Does it require skilled labor?
A4: No special training needed; operators can start after basic instruction.
